X-RAY Visual Inspection Machine CJ-RAY-51

​Product Use

​​​

Performance advantages:

1.PCB layer detection function, meeting various board thickness detection needs；
2.Independently developed high-definition imaging system for simple judgment；
3.Humanized software system with strong functional guidance and simple operation；
4.Modular mechanical structure, easy to maintain；
5 .15X-30X optical zoom to meet micro hole detection requirements；
6.Automatic start stop function to prevent the machine from being turned on for a long time。

​The main functions are as follows:

1.Measurement function: point-to-point, line to line, diameter, radius, concentric circles, layer displacement；

2.Application process: pressing (fusion and rivet alignment inspection), drilling (drilling head plate inspection)；

3.Software function: Can be connected to the internet, the software operation interface can save two pictures in real time, and can store pictures；

4.Radiation protection: The sheet metal adopts a sandwich structure of steel ladle lead, and the perspective window adopts lead glass to ensure safety；

5.Operating table: Made of high-quality marble to prevent flower arrangement on the PCB board；

6.Optional function: Optional printer for printing defective products；

7.Software operation: Power supply, voltage, image saving, and image processing can all be operated using software。

working conditions

1.occupied space：2.5m × 1m；

2.Working environment: Air temperature:+5~+40 ℃; Relative humidity: ≤ 80%；

3.working power supply：220V 50/60Hz。

Product Features

1. The X-ray tube can be designed to meet various plate thickness detection needs；

2.Independently developed high-definition imaging system for simple judgment；

3.Humanized software system, easy to operate；

4.Modular mechanical structure, easy to maintain；

5.Multiple calculation, measurement and other software functions；

6. 15-30x optical zoom to meet micro hole detection requirements；

7.Automatic start stop function to prevent the machine from being turned on for a long time。
